Pyrogrille – Circular Air Transfer Grilles for Services

Pyrogrille circular air transfer grilles are designed for installation into pipes, ductwork or air conditioning systems where they cross through dividing walls or partitions where the integrity of the building must be retained. Manufactured by Mann McGowan using high performance intumescent slats spaced 12mm apart, the finished units are 38mm thick and available in standard sizes. Providing up to 1.5 hours fire protection they provide excellent free air flow in normal use.

  • Up to 90 minutes fire protection
  • Easy to fit
  • Available in standard sizes of 100mm, 125mm, 150mm and 200mm
  • Maintenance free as no moving parts
  • Allows 50% air flow in normal use
  • Manufactured to size
  • Standard colour white, other colours available please ask for details
Category: Tags: , ,

Technical

Circular air transfer grilles for services

Description

PYROGRILLE air transfer grilles are manufactured from high performance intumescent slats, spaced 12mm apart. The thickness of the units are 38mm.

Performance

PYROGRILLES have been subjected to fire resistance tests in accordance with
BS 476 Part 20 : 1987 and assessed to Dutch Norm NEN 6069.

Applications

PYROGRILLE dampers must be secured within the ducting using 4 self tapping screws. On circular PYROGRILLES the screws should pass through the aluminium rings on the outer part of the PYROGRILLE. Clearance gaps should be sealed using PYROMAS A intumescent sealant.

Gaps around the PYROGRILLE unit greater than 3mm should be fire sealed using PYROMAS A intumescent sealant.

Finishes

Standard colour white.

Maintenance

Since there are no moving parts to go wrong, PYROGRILLES are easily maintained. Units should be cleaned using a damp cloth. Grease can be removed by using neat liquid detergent or methylated spirit. Strong degreasing agents should not be used nor should the units be immersed or saturated with water.

Ordering

When ordering please state, fire resistance required. Circular PYROGRILLE’s are available in standard sizes of 100mm, 125mm, 150mm and 200mm.
Non-standard sizes available on request.
